Spherical tantalum powder

Niobium nitride (NbN) has the advantages of high hardness, high wear resistance, high melting point and high chemical stability, and is widely used in metal cutting and protective coatings.

Molecular weight:180.94

Density:16.69 g/cm3

Colour:gray

Melting point:3017 °C

Boiling point:5458 °C

CAS NO.：7440-25-7

EINECS (EC NO.)：231-135-5

Share With:

Product Description Product Features Technical Specification Related Products

Product Description

Spherical tantalum powder has a series of excellent properties such as high melting point, low vapor pressure, good cold working performance, high chemical stability, strong resistance to liquid metal corrosion, and large surface oxide film dielectric constant. It is used in electronics, metallurgy, steel , Chemical, cemented carbide, atomic energy, superconducting technology, automotive electronics, aerospace, medical and health, scientific research and other high-tech fields have important applications.
Main properties:Spherical tantalum powder has high purity (99.95%), small particle size (50nm), low oxygen content (<200ppm), good sphericity (>95%), fewer satellite balls, and good fluidity.

Product Features

This product should be stored in a cool, dry room to avoid heavy pressure. It should not be exposed to the air during use, so as to avoid moisture absorption and agglomeration, which will affect the dispersion performance and use effect. Unused products should be sealed or stored in a vacuum after unpacking.

Technical Specification

Model	Purity	Average Particle Size （nm）			Specific surface area	Shape	Sphericility	The spherical rate
Model	Purity	D10	D50	D90	Specific surface area	Shape	Sphericility	The spherical rate
Ta（50nm）	≥99.9%	10-30	50-80	＜270	12 m2/g	spherical	＞95%	＞98%
Ta（100nm）	≥99.9%	30-60	50-100	＜1000	8.5 m2/g	spherical	＞95%	＞98%
Model	Purity	Average Particle Size（um）			fluidity	Shape	Sphericility	The spherical rate
Model	Purity	D10	D50	D90	fluidity	Shape	Sphericility	The spherical rate
Ta（1-10um）	≥99.9%	＞1	5±1	＜10	15 S/50g	spherical	＞95%	＞98%
Ta（5-30um）	≥99.9%	＞5	15±3	＜30	10 S/50g	spherical	＞95%	＞98%
Ta（10-50um）	≥99.9%	＞10	30±5	＜50	7.2 S/50g	spherical	＞95%	＞98%
